NVR Technical Specifications | ||
Model | NVR NVS002 | |
Video | Video Input | 8 Channel |
Video Output | 1* HDMI | |
1*VGA | ||
Video Resolution | 1080P/360P | |
Video Compression | H.265/ H.264/ Smart H.264 | |
Audio | Audio Input | NO |
Audio Output | NO | |
Audio Resolution | NO | |
Connection | NVR and camera Connection | Wi-Fi , Max 8Channel |
Network | WiFi | 2.4G |
Network | Protocol | Private Protocol |
LAN | Support | |
WAN | RJ45 Connection, support APP to remotely view 8 channels of monitoring screens at the same time | |
Hard Disk | Hard Drive | 1x SATA III Port, Up to 4 TB |
Capacity | Max Up to 4 TB | |
Record /Playback | Video | Planning video |
Alarm event recording | ||
Playback | Instant playback, regular playback, event playback | |
Video Backup | Support | |
Alarm | Motion Detection Alarm | Support |
Video Loss Alarm | Support | |
Alarm Reminder | Screen prompt, buzzer, APP push | |
Interface | Network Interface | 1* RJ45 |
USB Interface | 2*USB2.0 | |
HDMI Interface | 1*HDMI | |
VGA Interface | 1* VGA | |
Power Port | 1*DC 12V 2A (5.5*2.1*10 ) | |
Type | product Type | IP Camera , Indoor Use |
Others | Working Temperature | -10 to +50℃ |
Working Humidity | 10% to 90% RH | |
Size | Actual Size Final | |
Weight | About 850g (Actual Weight Final) | |
Certification | CE, FCC & RoHS | |
Wireless Camera Specifications | ||
Camera | Model | NVS002 |
Camera Quantity | Max 8 pieces Wireless Cameras | |
System | Main Processor | ARM11 |
Sensor | 1/2.7”, 2Megapixel progressive scan CMOS | |
Image Compression | H.265 | |
Lens | Lens Parameter | Focal length: 3.6mm, 2MP |
Angle of View | Horizontal:80°, Vertical: 58°, Diagonal: 98° | |
Video | Resolution | 1080P(1920x1080) / VGA(640x480) |
Image Frame Rate | 15fps - 25fps | |
Automatic Exposure | Adjust the image automatically to view clearly | |
Infrared Mode | Automatic | |
Night Visibility | Night Vision IR 10 meters | |
Min.Illuminatioin | 0.01 Lux / F1.2 (With IR Illuminator) | |
Filter Switch(IR-Cut) | Built-in IR Cut, no color deviation indoor or outdoor | |
Zoom | App supports 3x digital zoom | |
Audio | Audio | NO |
Alarm | Alarm | Motion detection alarm |
Alarm Notification | Push alarm notifications to your smartphone | |
Wireless | 2.4G IEEE 802.11 b/g/n, supports WEP, WPA & WPA2 Encryption | |
Software | SriHome App | iOS &Android |
Record | Record Mode | Motion detection alarm recording, 7/24 recording |
Storage | Hard drive ,up to 4TB | |
Others | Product Type | Mini card camera, waterproof for outdoor or indoor use |
Ingress Protection | IP66 | |
Power Supply | DC 5V | |
Working Temperature | -10 to +50℃ | |
Working Humidity | 10% to 90% RH | |
Weight | N.W.:140g (Note:Actual Weight Final) | |
Accessories | Adaptor, User Manual, Screws | |
Size | Item size: 84* 84* 100mm (LxWxH) | |
Packaging size: 115*117*171mm(LxWxH) | ||
Certification | CE, FCC & RoHS | |
Warranty | Limited 2-Year Warranty |
